무스웨이 4채널 앰프 MINI4S

Name: 무스웨이 4채널 앰프 MINI4S
Brand: musway
Price: 840000 KRW
Availability: InStock

840,000원

무스웨이(musway) 4채널 앰프 - 760Watts RMS

상세정보 접기

구매하기 설치상담 0

설치상담 설치상담

구매하기 구매하기

상세정보 접기

Model	MINI4S
Channels	4
Circuit	Digital Class D
Power RMS @ 14.4V(<1% THD+N) Watts @ 4 Ohms Watts @ 2 Ohms Watts @ 4 Ohms bridged	CH1-CH4 4 x 130 4 x 210 2 x 420
Frequency Range	18-29000Hz@-3dB
Signal-to-noise Ratio	>107dB
THD+N@10W	<0.08%
Input Sensitivity	High Level : 1.5V-20V Low Level : 0.7V-10V
Filter Section CH1/CH2 Low Pass Filter or High Pass Filter	50-4000Hz
Filter Section CH3/CH4 Low Pass Filter or High Pass Filter	50-4000Hz
CH3/CH4 Bass Boost@45Hz	0-12dB
Operating Voltage	8.5-17V(max.5 sec.down to 7V)
Start-stop Capability	∨
High Level Input with EPS** only via included Cable Connector	∨ Type D
Auto Turn-on only via High Level Input	∨
Bass Level Remote Controller	∨
Fuse(external)	2 X 35A(Internal)
Dimensions Width Height Length	94mm 41mm 165mm

Model	MINI4S
Channels	4
Circuit	Digital Class D
Power RMS @ 14.4V(<1% THD+N) Watts @ 4 Ohms Watts @ 2 Ohms Watts @ 4 Ohms bridged	CH1-CH4 4 x 130 4 x 210 2 x 420
Frequency Range	18-29000Hz@-3dB
Signal-to-noise Ratio	>107dB
THD+N@10W	<0.08%
Input Sensitivity	High Level : 1.5V-20V Low Level : 0.7V-10V
Filter Section CH1/CH2 Low Pass Filter or High Pass Filter	50-4000Hz
Filter Section CH3/CH4 Low Pass Filter or High Pass Filter	50-4000Hz
CH3/CH4 Bass Boost@45Hz	0-12dB
Operating Voltage	8.5-17V(max.5 sec.down to 7V)
Start-stop Capability	∨
High Level Input with EPS** only via included Cable Connector	∨ Type D
Auto Turn-on only via High Level Input	∨
Bass Level Remote Controller	∨
Fuse(external)	2 X 35A(Internal)
Dimensions Width Height Length	94mm 41mm 165mm
